Customizable Polyurethane PU Rod 30 - 40MPa Urethane Round Rod Stock

Large Image : Customizable Polyurethane PU Rod 30 - 40MPa Urethane Round Rod Stock

Product Details:

Place of Origin:	China
Brand Name:	jiuna
Certification:	iso9001:2015
Model Number:	10mm-300mm

Payment & Shipping Terms:

Minimum Order Quantity:	100 PIECES
Packaging Details:	Wooden Case or Woven Bags, Pallet
Delivery Time:	7working days
Supply Ability:	100 Tons/Per Month

Contact Now Chat Now

Customizable Polyurethane PU Rod 30 - 40MPa Urethane Round Rod Stock

Description

Tensile Strength:	30-40MPa	Resistant To:	Oils, Greases, Solvents, And Many Chemicals
Diameter:	10mm-300mm	Specification:	Standard Or Customized
Origin:	China	Production Capacity:	100 Tons/Per Month
Contraction Percentage:	1.0%-2.5%	Hardness:	60A-95A
Process:	Moulding ,Cutting	Transport Package:	Wooden Case Or Woven Bags, Pallet
HS Code:	3926909090
Highlight:	PU Rod 30MPa , PU Rod 40MPa , Customizable Urethane Round Rod Stock

Customizable Polyurethane PU Rod Natural Color Urethane Round Rod Stock

Product Attributes

Attribute	Value
Tensile Strength	30-40MPa
Resistant to	Oils, Greases, Solvents, and Many Chemicals
Diameter	10mm-300mm
Specification	standard or customized
Origin	China
Production Capacity	100 Tons/Per Month
Contraction Percentage	1.0%-2.5%
Hardness	60A-95A
Process	Moulding, Cutting
Transport Package	Wooden Case or Woven Bags, Pallet
HS Code	3926909090

Product Description

PU rods are specialist materials used widely in machining applications to provide durable solutions for manufacturing lines. Made from premium-quality polyurethane, these cylindrical rods are available in various thicknesses to meet project requirements.

Variable shore hardness levels between 40 and 90°A
Available in multiple colors
Excellent resistance to chemicals
Superior durability compared to traditional materials like rubber
Stable performance in extreme temperatures

Standard Specifications

ITEM No.	Specification
RDB01030	OD : 10mm x L : 300mm
RDB01230	OD : 12mm x L : 300mm
RDB01430	OD : 14mm x L : 300mm
RDB01530	OD : 15mm x L : 300mm
RDB01650	OD : 16mm x L : 500mm
RDB01850	OD : 18mm x L : 500mm
RDB02050	OD : 20mm x L : 500mm
RDB02250	OD : 22mm x L : 500mm
RDB02550	OD : 25mm x L : 500mm
RDB02850	OD : 28mm x L : 500mm
RDB03050	OD : 30mm x L : 500mm
RDB03250	OD : 32mm x L : 500mm
RDB03550	OD : 35mm x L : 500mm
RDB04050	OD : 40mm x L : 500mm
RDB04550	OD : 45mm x L : 500mm
RDB05050	OD : 50mm x L : 500mm
RDB05550	OD : 55mm x L : 500mm
RDB06050	OD : 60mm x L : 500mm
RDB06350	OD : 63mm x L : 500mm
RDB06550	OD : 65mm x L : 500mm
RDB07050	OD : 70mm x L : 500mm
RDB07550	OD : 75mm x L : 500mm
RDB08050	OD : 80mm x L : 500mm
RDB08550	OD : 85mm x L : 500mm
RDB09050	OD : 90mm x L : 500mm
RDB09550	OD : 95mm x L : 500mm
RDB10050	OD : 100mm x L : 500mm
RDB11050	OD : 110mm x L : 500mm
RDB12050	OD : 120mm x L : 500mm
RDB12550	OD : 125mm x L : 500mm
RDB13050	OD : 130mm x L : 500mm
RDB14050	OD : 140mm x L : 500mm
RDB15050	OD : 150mm x L : 500mm
RDB16050	OD : 160mm x L : 500mm
RDB17050	OD : 170mm x L : 500mm
RDB17550	OD : 175mm x L : 500mm
RDB18050	OD : 180mm x L : 500mm
RDB20050	OD : 200mm x L : 500mm
RDB22550	OD : 225mm x L : 500mm
RDB25050	OD : 250mm x L : 500mm
RDB27550	OD : 275mm x L : 500mm
RDB30050	OD : 300mm x L : 500mm

Physical Properties

Property	Value
Hardness, Shore A	90
100% Modulus, psi	1330
300% Modulus, psi	2380
Tensile, psi	5475
Elongation, %	431
Tear Strength (D624), pli Die C	293
Tear Strength (D1938), pli Die C	125
Bashore Rebound, %	42
Compression Set (22 hrs @ 70℃), %	32
Bell Brittle, ℃	>62
Specific Gravity, g/cm3	1.13

Notice: These values are based on the test of our present laboratory test specimens.
